CX006 Diesel Mini Excavator | 690mm Narrow Compact Digger
CX006 Diesel Mini Excavator | 690mm Narrow Compact Digger
Ningbo ACE Machinery developed the CX-006 for residential construction, landscaping, urban renovation and other tight-access projects. With a body width of only 690 mm, this narrow mini excavator can pass through garden gates, side paths, alleyways and confined job sites where larger machines often struggle. In addition, the machine offers an operating weight of over 790 kg, hydraulic pressure up to 170 bar, 690 kgf bucket digging force and 390 kgf arm digging force. Buyers can choose Loncin petrol, Briggs & Stratton petrol or Kubota Z482 diesel power. Therefore, the CX-006 works well as a diesel mini excavator, rubber track mini excavator, Kubota engine mini excavator or hydraulic mini excavator for trenching, drainage, landscaping and renovation work.
Quote Now
Key Highlights of the CX006 Compact Excavator
- 690 mm narrow access width helps the machine pass through garden gates, side paths and confined construction areas.
- Over 790 kg operating weight gives better working stability than many very light micro diggers.
- Kubota Z482 diesel engine option supports users who prefer a reliable diesel power unit.
- Rubber track undercarriage helps reduce surface damage on lawns, paving and residential ground.
- 65° left and 70° right boom swing makes trenching beside walls, fences and drainage lines easier.
- Hydraulic system with 170 bar pressure gives smooth control and practical digging performance.
Product Advantages
690 mm Narrow Body for Restricted Access
The CX-006 measures only 690 mm wide. As a result, it can enter many spaces that standard compact excavators cannot reach. It works well in garden gates, narrow side paths, courtyards, alleyways and indoor renovation areas.
For this reason, landscapers, builders, rental companies and small contractors can use this narrow mini excavator on tight European job sites without spending extra time on access preparation.
Kubota Diesel Engine Option for Professional Use
Users who prefer diesel power can choose the Kubota Z482 twin-cylinder diesel engine. It delivers 9.3 kW at 3,600 rpm and supports regular construction, landscaping and trenching work.
In addition, ACE Machinery also offers Loncin and Briggs & Stratton petrol engine options. Therefore, buyers can match the machine to local fuel habits, maintenance needs and market preferences.
Rubber Tracks for Lower Ground Disturbance
The 180 mm wide rubber tracks help protect lawns, paving, tiles and finished residential surfaces. Moreover, the low ground pressure of 0.27 kg/cm² helps the CX-006 work on softer or more sensitive ground.
This makes it a practical rubber track mini excavator for gardens, courtyards, private homes and small renovation projects where surface protection matters.
Standard ROPS Protective Frame
The CX-006 comes with a standard ROPS protective frame. This structure helps improve operator protection during daily construction, landscaping and rental use.
For contractors and hire companies, this safety feature adds confidence when operators work on uneven ground, narrow paths or confined job sites.
Swing Boom for Digging Beside Walls and Fences
The hydraulic boom swing moves 65° to the left and 70° to the right. Because of this, the operator can dig beside walls, fences, foundations and drainage channels without moving the whole machine repeatedly.
On narrow sites, this feature saves time and makes trenching work easier, especially when the machine has limited space to turn.
Easy Transport Between Small Job Sites
The CX-006 has a transport weight of over 715 kg and compact dimensions of 2150 × 690 × 2080 mm. Therefore, users can move it more easily than larger excavators.
This is useful for landscapers, sole traders, rental users and small construction teams who need to move between several small job sites in one day.
Why Choose the CX006 Mini Excavator?
The CX006 gives users narrow access, useful digging performance and simple transport in one compact excavator. Its 690 mm body width helps it enter restricted spaces, while the rubber tracks, hydraulic boom swing and Kubota diesel engine option support landscaping, backyard trenching, drainage work and residential renovation. Therefore, it is a practical choice for European job sites where space is limited but performance still matters.
Optional Equipment
- Standard bucket
- Ditch cleaning bucket
- Swivelling bucket
- Special paint customisation
Product Parameters
Dimensions & Weight
| Transport Dimensions (L × W × H) | 2,150 × 690 × 2,080 mm |
| Machine Width | 690 mm |
| Max. Machine Height | 2,080 mm |
| Operating Weight ±2% (EC Norms) | > 790 kg |
| Transport Weight ±2% (EC Norms) | > 715 kg |
| Rear Swing Radius | 735 mm |
| Reduced Rear Overhang | 240 mm |
| Ground Clearance | 155 mm |
| Shoe Width | 180 mm |
| Blade (Width × Height) | 580 × 170 mm |
Engine Options
| Engine 1 — Loncin Gasoline, 1-cylinder | Loncin G300F(D)A · 6.8 kW / 3,600 rpm · 302 cm³ · 20.3 N·m |
| Engine 2 — Briggs & Stratton Gasoline, 1-cylinder | 19N1 · 10.0 HP / 3,600 rpm |
| Engine 3 — Kubota Diesel, 2-cylinder | Kubota Z482 · 9.3 kW / 3,600 rpm |
Hydraulic Circuit
| System Capacity | 7.8 L |
| Max. Pressure | 170 bar |
| Gear Pumps (×2) | 2 × 6.92 L/min |
Performance
| Max. Digging Depth | 1,200 mm |
| Max. Digging Reach | 2,300 mm |
| Digging Force — Arm / Bucket | 390 / 690 kgf |
| Boom Swing (Left / Right) | 65° / 70° |
| Travelling Speed | 2.0 km/h |
| Swing Speed | 8 rpm |
| Ground Pressure | 0.27 kg/cm² |
| Grade Ability | 25° |
Miscellaneous
| Fuel Tank | 6 L |
| Cooling System | 2 L |
| Noise Level LwA (2000/14/EC & 2005/88/EC) | 101 dBA |
Optional Equipment
| Standard Bucket | Optional |
| Ditch Cleaning Bucket | Optional |
| Swivelling Bucket | Optional |
| Special Paint | Optional |
Why Choose Us.
Frequently Asked Questions
A: Compact or mini excavators are built for digging in confined jobsites. Most models feature a hydraulic-powered arm attached to a track-mounted chassis.
Construction, landscaping and farm & orchard professionals rely on mini excavators to work where larger machines can’t fit. They can maneuver between buildings and around obstacles with minimal or zero tail swing, giving them an advantage over large excavators.
A: ACE compact (mini) excavators range in operating weights:
The smallest ACE mini excavator model, the CX10T, weighs 1020 kgs.
The heaviest ACE mini excavator, the CX36, weighs 3800 kgs.
Additional factors that affect compact excavator weight:
- Attachments for your excavator can add hundreds of kilo grams.
- Steel tracks increase weight compared to rubber tracks.
- Other features like enclosed cabs or add-on counterweights also contribute to overall weight.
A: Operating a mini excavator isn’t hard, but it requires proper training. With ACE operator training courses, you can quickly learn what you need to know:
- Safe and efficient operation
- Understanding of key components and safety features
- Detailed explanations of controls and functions
- Maneuvering, traveling and working safely
Courses are available online to learn at your own pace. They make learning easy with interactive videos, graphics, quizzes and more.
A: Excavator prices vary based on features, options, location and other factors. Contact ACE Sales Engineer +86 191 5798 3137 or local distributors for accurate pricing, or use our Build & Quote tool to customize your own machine and receive a quote from us.
A: ACE compact excavators are exclusively available from ACE ASOK and our authorized distributors. Contact us to get industry-leading sales, service and support.
A: Absolutely yes, we provide customization service range including: logo, color and accessories, etc. for some special requirement in its functionality, you are more than welcome to contact our sale engineer for further help.
