- Imported engine, motor adopted to keep its quality stable.
- Small batch customization service is welcome.
- Complete machine warranty as long as 2 years.
- Multi-channel delivery of after-sales service via Youtube, Facebook and our global distributors.
- All excavators are fixed by wood strip in shipping in order not lead to any damage.
CX11B compact crawler excavator source factory wholesale
CX11B compact crawler excavator source factory wholesale
CX11B Mini Crawler Excavator is strictly complete tested and inspected before shipment in order to assure your 100% satisfaction.
CX11 series mini excavator, with its ultra-compact design, enhanced safe protection, zero tail swing, etc. is to help get the job well done.
Quote Now
CX11B compact crawler excavator source factory wholesale – MADE BY ACE ASOK®
Product Parameters
| General Information | |
| Opration Weight | 1120 kgs |
| Bucket Capacity | 0.025 cbm |
| Bucket Width | 380 mm |
| Boom Length | 1480 mm |
| Arm Length | 793 mm |
| Dimensions | |
| Length Of Track | 1220 mm |
| Ground Clearance Of Upper Plastform | 360 mm |
| Turning Radius Of Tail | 780 mm |
| Width | 930 mm |
| Width Of Track | 180 mm |
| Height Of Track | 320 mm |
| Length | 2750 mm |
| Whole Height (Without/With Ceiling) | 1500/2140 mm |
| Engine | |
| Model | Koop KD192F |
| Rated Power | 8.6/3000 kW/rpm |
| Displacement | 0.499L |
| Number Of Cylinder | 1 |
| Bore X Stroke | 95 X 75 mm |
| Cooling Way | Air cooled |
| Operating Range | |
| Maximun Digging Radius | 2890 mm |
| Maximun Digging Depth | 1720 mm |
| Maximun Digging Height | 2600 mm |
| Maximun Unloading Height | 1890 mm |
| Push Plate Length & Width | 930 X 205 mm |
| Push Plate Pushing Height & Depth | 135/255 mm |
| Boom Turning Angle | Left 50°/Right 70° |
Why Choose Us.
Frequently Asked Questions
A: Compact or mini excavators are built for digging in confined jobsites. Most models feature a hydraulic-powered arm attached to a track-mounted chassis.
Construction, landscaping and farm & orchard professionals rely on mini excavators to work where larger machines can’t fit. They can maneuver between buildings and around obstacles with minimal or zero tail swing, giving them an advantage over large excavators.
A: ACE compact (mini) excavators range in operating weights:
The smallest ACE mini excavator model, the CX10T, weighs 1020 kgs.
The heaviest ACE mini excavator, the CX36, weighs 3800 kgs.
Additional factors that affect compact excavator weight:
- Attachments for your excavator can add hundreds of kilo grams.
- Steel tracks increase weight compared to rubber tracks.
- Other features like enclosed cabs or add-on counterweights also contribute to overall weight.
A: Operating a mini excavator isn’t hard, but it requires proper training. With ACE operator training courses, you can quickly learn what you need to know:
- Safe and efficient operation
- Understanding of key components and safety features
- Detailed explanations of controls and functions
- Maneuvering, traveling and working safely
Courses are available online to learn at your own pace. They make learning easy with interactive videos, graphics, quizzes and more.
A: Excavator prices vary based on features, options, location and other factors. Contact ACE Sales Engineer +86 191 5798 3137 or local distributors for accurate pricing, or use our Build & Quote tool to customize your own machine and receive a quote from us.
A: ACE compact excavators are exclusively available from ACE ASOK and our authorized distributors. Contact us to get industry-leading sales, service and support.
A: Absolutely yes, we provide customization service range including: logo, color and accessories, etc. for some special requirement in its functionality, you are more than welcome to contact our sale engineer for further help.
