- Imported engine, motor adopted to keep its quality stable.
- Small batch customization service is welcome.
- Complete machine warranty as long as 2 years.
- Multi-channel delivery of after-sales service via Youtube, Facebook and our global distributors.
- All excavators are fixed by wood strip in shipping in order not lead to any damage.
CX18 best compact excavator for Tight urban areas crawler excavator for sale
CX18 best compact excavator for Tight urban areas crawler excavator for sale
The CX18 hydraulic mini excavator is designed specifically for working in confined spaces, combining flexibility and practicality. Key design highlights include a zero-tail swing mechanism and a retractable chassis, enabling efficient operation in areas difficult to access with traditional excavators, replacing manual digging and improving construction efficiency.
Quote Now
CX-18 Mini Excavator – Detailed Description
The CX18 excavator’s core strength lies in its exceptional adaptability and operational flexibility, making it particularly suitable for small-scale projects such as municipal maintenance, landscaping renovations, and interior demolition. Its load-sensing hydraulic system and automatic shifting technology enhance operational fluidity and fuel efficiency.
Detailed explanation of the advantages of CX18
- Hydraulic system: Load-sensing technology ensures smooth operation and low energy loss.
- Lightweight design: Standard operating weight is 1780 kg, resulting in minimal ground damage.
- Flexible operation: The retractable chassis provides both maneuverability and stability.
- Easy maintenance: Lubricated rollers and sealed track chains reduce maintenance costs.
The CX18 mini excavator is suitable for a variety of applications.
The CX-18 is well-suited for:
- Small projects: municipal pipeline excavation, basement backfilling, and interior demolition.
- Landscaping: tree transplanting, landscaping, and trench excavation.
- Agricultural applications: greenhouse construction, farmland irrigation, and farm desilting.
Product Parameters
| model | CX18 | |
| Machine Dimensions | Arm Length | 940 mm |
| Overall Length | 3584 mm | |
| Overall Height | 2362 mm | |
| Overall Width (over tracks) | Minimum | 990 mm |
| Maximum | 1300 mm | |
| Tail-Swing Radius | 660 mm | |
| Tumbler Distance | 1223 mm | |
| Overall Length of Crawler | 1251 mm | |
| Counterweight Clearance | 448 mm | |
| Overall Height (to top of cab) | 2362 mm | |
| Ground Clearance | 156 mm | |
| Overall Width of Upperstructur | 980 mm | |
| Track Gauge | 760 mm | |
| Shoe Width | 230 mm | |
| Operating Dimensions | Arm Length | 940 mm |
| Maximum Reach | 3899 mm | |
| Maximum Reach at Ground Leve | 3848 mm | |
| Maximum Digging Depth | 2326 mm | |
| Maximum Cutting Height | 3462 mm | |
| Maximum Loading Height | 2436 mm | |
| Minimum Slew Radius | 1372 mm | |
| Maximum Vertical Wall Digging Depth | 1713 mm | |
| Tail-Swing Radius | 660 mm | |
| Engine type | Japanese brand Yanmar 3TNV80,Euro 5 emission | |
| Engine power | 14.6 KW | |
| Operation Weight(Kgs) | 1780kg | |
| Bucket capacity | 0.05m³ | |
| Arm rotatable or not | Rotatable | |
| Operating system | Pilot operation | |
| Chasis | Undercarriage Vinyl seat (canopy only) | |
| Walking Motor | Hinged service-access doors Alternator, 55 amp | |
| Price(FOB Ningbo,China) | ||
| Accessory for Optional | 200 mm bucket (with tooth) | |
| 300 mm bucket (with tooth) | ||
| 500 mm bucket (with tooth) | ||
| 600 mm bucket (without tooth) | ||
| Quick hitch | ||
| Ripper | ||
| Wood Grab | ||
| 800 mm Hydraulic bucket (without tooth) | ||
| Rake 800mm | ||
| Auger (Drill width 400mm) | ||
| Hydraulic Breaker | ||
| Trailer | ||
Why Choose Us.
Frequently Asked Questions
A: Compact or mini excavators are built for digging in confined jobsites. Most models feature a hydraulic-powered arm attached to a track-mounted chassis.
Construction, landscaping and farm & orchard professionals rely on mini excavators to work where larger machines can’t fit. They can maneuver between buildings and around obstacles with minimal or zero tail swing, giving them an advantage over large excavators.
A: ACE compact (mini) excavators range in operating weights:
The smallest ACE mini excavator model, the CX10T, weighs 1020 kgs.
The heaviest ACE mini excavator, the CX36, weighs 3800 kgs.
Additional factors that affect compact excavator weight:
- Attachments for your excavator can add hundreds of kilo grams.
- Steel tracks increase weight compared to rubber tracks.
- Other features like enclosed cabs or add-on counterweights also contribute to overall weight.
A: Operating a mini excavator isn’t hard, but it requires proper training. With ACE operator training courses, you can quickly learn what you need to know:
- Safe and efficient operation
- Understanding of key components and safety features
- Detailed explanations of controls and functions
- Maneuvering, traveling and working safely
Courses are available online to learn at your own pace. They make learning easy with interactive videos, graphics, quizzes and more.
A: Excavator prices vary based on features, options, location and other factors. Contact ACE Sales Engineer +86 191 5798 3137 or local distributors for accurate pricing, or use our Build & Quote tool to customize your own machine and receive a quote from us.
A: ACE compact excavators are exclusively available from ACE ASOK and our authorized distributors. Contact us to get industry-leading sales, service and support.
A: Absolutely yes, we provide customization service range including: logo, color and accessories, etc. for some special requirement in its functionality, you are more than welcome to contact our sale engineer for further help.
Get Quote Now!
Welcome to discuss your purchasing requirements with our customer service.
